DUAL COMPARATOR,VCC:36V
Product Category: Analog Comparators
Manufacturer: ON Semiconductor
RoHS: No
Mounting Style: SMD/SMT
Package/Case: SOIC-8
Comparator Type: General Purpose
Number of Channels: 2 Channel
Output Type: Rail-to-Rail
Output Current per Channel: 16 mA
Ib – Input Bias Current: 50 nA
Vos – Input Offset Voltage: 5 mV
Supply Voltage – Max: 36 V
Supply Voltage – Min: 2 V
Operating Supply Current: 1 mA
Response Time: 1.5 us
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
Packaging: Tube
Brand: ON Semiconductor
Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
GBP – Gain Bandwidth Product: –
Height: 1.5 mm (Max)
Length: 5 mm (Max)
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: 1 V
Operating Supply Voltage: 3 V, 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Pd – Power Dissipation: 570 mW
Product: Analog Comparators
Reference Voltage: Yes
Shutdown: No Shutdown
Factory Pack Quantity: 2500
Supply Type: Single, Dual
Technology: Bipolar
Type: Low Offset Comparator
Vcm – Common Mode Voltage: Negative Rail to Positive Rail – 1.5 V
Voltage Gain dB: 106.02 dB
Width: 4 mm (Max)
Unit Weight: 540 mg
آی سی LM293 یک مقایسه گر آنالوگ 2 کانال می باشد.
