QUAD,JFET LOW POWER OPAMP
Product Category: Operational Amplifiers – Op Amps Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Mounting Style: Through Hole
Package/Case: PDIP-14
Supply Voltage – Max: 36 V
Number of Channels: 4 Channel
GBP – Gain Bandwidth Product: 1 MHz
SR – Slew Rate: 3.5 V/us
CMRR – Common Mode Rejection Ratio: 70 dB
Ib – Input Bias Current: 400 pA
Vos – Input Offset Voltage: 15 mV
Supply Voltage – Min: 7 V
Operating Supply Current: 1 mA
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
Shutdown: No Shutdown
Series: TL064
Packaging: Tube
Amplifier Type: Low Power Amplifier
Brand: Texas Instruments
Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
en – Input Voltage Noise Density: 42 nV/sqrt Hz
Height: 4.57 mm
Length: 19.3 mm
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 3.5 V
Operating Supply Voltage: 7 V to 36 V, +/- 3.5 V to +/- 18 V
Product: Operational Amplifiers
Factory Pack Quantity: 25
Supply Type: Single, Dual
Technology: BiFET
Vcm – Common Mode Voltage: Negative Rail + 4 V to Positive Rail – 4 V
Voltage Gain dB: 75.56 dB
Width: 6.35 mm
Unit Weight: 1 g
آی سی TL064یک (آپ امپ )تقویت کننده 4تایی با ورودی JFET و با توان پایین میباشد .
