Hex Inverter-CMOS
Product Category: Flip-Flops Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Number of Circuits: 2
Logic Family: CD4000
Logic Type: D-Type Register
Polarity: Non-Inverting
Input Type: CMOS
Output Type: CMOS
Propagation Delay Time: 600 ns
High Level Output Current: – 1.5 mA
Low Level Output Current: 1.5 mA
Supply Voltage – Max: 18 V
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package/Case: PDIP-16
Packaging: Tube
Brand: Texas Instruments
Function: 4-Bit D-Type
Height: 4.57 mm
Length: 19.3 mm
Minimum Operating Temperature: – 55 C
Number of Channels: 4
Number of Input Lines: 4
Number of Output Lines: 3
Operating Supply Voltage: 10 V
Operating Temperature Range: – 55 C to + 125 C
Quiescent Current: 100 uA
Reset Type: Master Reset
Series: CD4076B HCF4076B , HEF4076B , TC4076B
Factory Pack Quantity: 25
Supply Voltage – Min: 3 V
Width: 6.35 mm
Unit Weight: 1 g
آی سی CD4076B شمل 2 فلیپ فلاپ نوع D می باشد.
