TTL 7442-1-10 LINE DECODER BCD/DECIMAL
Product Category: Encoders, Decoders, Multiplexers & Demultiplexers Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Product: Decoders / Demultiplexers
Logic Family: LS
Number of Input Lines: 4 Input
Number of Output Lines: 10 Output
Propagation Delay Time: 30 ns
Supply Voltage – Max: 5.25 V
Supply Voltage – Min: 4.75 V
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package/Case: PDIP-16
Packaging: Tube
Brand: Texas Instruments
Function: 4 to 10 BCD
Height: 4.57 mm
High Level Output Current: – 0.4 mA
Input Voltage: 2.0 V to 0.8 V
Length: 19.3 mm
Logic Type: Decoder
Low Level Output Current: 8 mA
Maximum Clock Frequency: 35 MHz
Minimum Operating Temperature: 0 C
Number of Circuits: Dual
Operating Supply Voltage: 5 V
Operating Temperature Range: 0 C to + 70 C
Output Current: 8 mA
Output Voltage: + 0.4 V to + 0.5 V
Series: SN74LS42
Factory Pack Quantity: 25
Supply Current – Max: 7 mA
Technology: Bipolar
Width: 6.35 mm
Unit Weight: 1 g
آی سی 74LS42 یک مبدل کد BCD به دسیمال(10تایی) می باشد .
