TTL 7407-K BUFFER-OPEN/C OUTPUT 14PIN
Product Category: Buffers & Line Drivers Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Number of Input Lines: 6 Input
Number of Output Lines: 6 Output
Polarity: Non-Inverting
Supply Voltage – Max: 5.25 V
Supply Voltage – Min: 4.75 V
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package/Case: PDIP-14
Packaging: Tube
Brand: Texas Instruments
Function: Buffer/Driver
Height: 3.3 mm
High Level Output Current: – 0.25 mA
Input Signal Type: Single-Ended
Length: 19.05 mm
Logic Family: LS
Logic Type: Bipolar
Low Level Output Current: 40 mA
Minimum Operating Temperature: 0 C
Number of Channels: 5
Operating Supply Current: 45 uA
Operating Supply Voltage: 5 V
Operating Temperature Range: 0 C to + 70 C
Output Type: Open Collector
Pd – Power Dissipation: 140 mW
Propagation Delay Time: 30 ns at 5 V
Series: SN74LS07
Factory Pack Quantity: 25
Technology: Bipolar
Width: 6.35 mm
Unit Weight: 1 g
آی سی 74LS07دارای 6 عدد بافر است که می توان برای تبدیل سطح ولتاژ TTL به CMOS، درایو کردن رله و … استفاده کرد.
