SMD,Quad 2-Input AND Gate-CMOS
Product Category: Logic Gates
Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Product: Single-Function Gate
Logic Function: AND
Logic Family: CD4000
Number of Gates: 4 Gate
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
High Level Output Current: – 1.5 mA
Low Level Output Current: 1.5 mA
Propagation Delay Time: 12 ns
Supply Voltage – Max: 18 V
Supply Voltage – Min: 3 V
Maximum Operating Temperature: + 125 C
Mounting Style: SMD/SMT
Package/Case: SOIC-14
Packaging: Reel
Brand: Texas Instruments
Function: AND
Height: 1.58 mm
Input Type: CMOS
Length: 8.65 mm
Logic Type: 2-INPUT AND
Minimum Operating Temperature: – 55 C
Number of Bits: 4 bit
Operating Supply Current: 15 uA
Operating Supply Voltage: 10 V
Operating Temperature Range: – 55 C to + 125 C
Output Type: CMOS
Quiescent Current: 20 nA
Series: CD4081B , HEF4081BT , HCF4081B , TC4081B
Factory Pack Quantity: 2500
Width: 3.91 mm
Unit Weight: 0.5 mg
آی سی CD4081B شامل 4 عدد گیت NAND با دو ورودی می باشد.
