TTL 74540-OCTAL BUFFER/LINE DRIVER
Product Category: Buffers & Line Drivers Manufacturer: NXP
Number of Input Lines: 8 Input
Number of Output Lines: 8 Output
Polarity: Inverting
Supply Voltage – Max: 6 V
Supply Voltage – Min: 2 V
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package/Case: DIP-20 (SOT-146)
Packaging: Tube
Brand: NXP Semiconductors
Function: Buffer/Line Driver
Height: 3.2 mm (Max)
High Level Output Current: – 7.8 mA
Input Signal Type: Single-Ended
Length: 26.92 mm (Max)
Logic Family: HC
Logic Type: CMOS
Low Level Output Current: 7.8 mA
Minimum Operating Temperature: – 40 C
Number of Channels: 8
Operating Supply Voltage: 5 V
Output Type: 3-State
Pd – Power Dissipation: 750 mW
Propagation Delay Time: 30 ns
Quiescent Current: 8 uA
Factory Pack Quantity: 18
Supply Current – Max: 8 uA
Technology: CMOS
Width: 6.4 mm (Max)
آی سی SN74HC540N یک بافر اکتال ( 8 تایی) یا راه انداز خط و خروجی معکوس کننده با فرمان 3 حالته می باشد.
