TTL 74365-6-BIT BUFF.& DRIVER,NON-INVERT
Product Category: Buffers & Line Drivers
Manufacturer: Texas Instruments
RoHS: RoHS Compliant Details
Number of Input Lines: 6 Input
Number of Output Lines: 6 Output
Polarity: Non-Inverting
Supply Voltage – Max: 6 V
Supply Voltage – Min: 2 V
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package/Case: SOIC-16
Packaging: Tube
Brand: Texas Instruments
Function: Buffer/Line Driver
Height: 1.5 mm (Max)
High Level Output Current: – 7.8 mA
Input Signal Type: Single-Ended
Length: 10 mm (Max)
Logic Family: HC
Logic Type: CMOS
Low Level Output Current: 7.8 mA
Minimum Operating Temperature: – 40 C
Number of Channels: 5
Operating Supply Current: 80 uA
Operating Supply Voltage: 2 V to 6 V
Operating Temperature Range: – 40 C to + 85 C
Output Type: 3-State
Propagation Delay Time: 120 ns at 2 V, 24 ns at 4.5 V, 20 ns at 6 V
Quiescent Current: 8 uA
Series: SN74HC365
Factory Pack Quantity: 40
Supply Current – Max: 8 uA
Technology: CMOS
Width: 4 mm (Max)
Unit Weight: 141mg
آی سی 74HC365 یک بافر / باس درایور با خروجی 3 حالته می باشد که توسط پایه های ورودی کنترل می شوند.
